Description
This 304 stainless steel sanitary flame arrester with integrated breather function is designed for pipelines and storage tanks handling flammable or explosive gases and liquids. It combines reliable flame quenching with pressure and vacuum relief, making it ideal for food, beverage, dairy, brewing, pharmaceutical, and fine chemical applications.
The unit features a dual flame arrestor element design. Two stainless steel arrestor cores are installed in opposite orientation, providing significantly better flame-stopping performance than single-element designs. The sanitary Tri-Clamp connections allow fast installation and removal for cleaning or inspection, while the polished 304 stainless steel construction offers excellent corrosion resistance and easy cleanability.
Key Applications
- Storage tank venting and breathing
- Process pipelines carrying alcohol, solvents, or flammable gases
- Brewing, distilling, and beverage production
- Dairy and food processing systems
- Pharmaceutical and biotech vessels
- Fine chemical and solvent recovery systems
Why Choose This Design
- Dual flame arrestor elements for superior flame quenching
- Fully sanitary construction with Tri-Clamp ends
- Lightweight yet robust 304 stainless steel body
- Easy to disassemble, inspect, and clean
- Suitable for continuous operation in hygienic environments
- Tested to withstand prolonged flame exposure without flashback
Available in φ38 (approx. 1.5″) and φ51 (approx. 2″) Tri-Clamp sizes. Custom sizes and configurations available upon request.
| Parameter | Specification |
|---|---|
| Product Name | Sanitary Flame Arrester with Breather Valve |
| Material | 304 Stainless Steel |
| Connection Type | Tri-Clamp (Sanitary Quick Clamp) |
| Available Sizes | φ38 (≈1.5″), φ51 (≈2″) |
| Operating Temperature | -20°C to +120°C |
| Operating Pressure | 0.2 – 0.5 MPa |
| Flame Arrestor Design | Dual stainless steel element (opposed orientation) |
| Body Finish | Polished sanitary finish |
| Function | Flame quenching + Pressure/Vacuum relief |
| Suitable Media | Flammable gases, vapors, and liquids |
| Typical Applications | Food, beverage, dairy, brewing, pharmaceutical, fine chemical, alcohol and solvent systems |
| Installation | In-line or tank vent |
| Cleaning | Easy disassembly for inspection and CIP |
| Packaging | Bubble wrap + carton |
| Customization | Available (non-standard sizes and configurations) |
